Instroduction:

The company has a well-trained production team supported by in-house CAD, software, hardware design engineers and well established vendors to support production target and a management that understands the importance of quality and timely delivery. This together with a flexible production process and cost effective operations has enabled it to be competitive, responsive and reliable. The company provides validation and prompt after sales service for its customers needs.

  • Measures 5 parameters – Weight, Thickness, Diameter (Length), Width and Hardness

  • Full color intuitive touch screen display

  • Constant speed and constant force measuring principle

  • Up to 21 samples per test

  • Multilevel level user management security

  • Indicator for calibration due date

  • Light and audio alarm indicator for Instrument status

  • Programmable calibration and verification modes

  • User selectable templates for printing reports and graphs

  • Protective cover to protect operator from inhaling tablet

  • dust from tablets that ‘explode

  • External Weighing balance

  • Finger print sensor

  • Audit trial

  • E-signature

  • 1000 products

  • 50 methods

  • 10000 reports

  • log book

  • 250 users

  • Built in thermal printer

  • Model: EHT-5PR TURBO
  • Parameter: Weight, Internal Thickness/ External Thickness,
    Diameter/ Length, Width, Hardness
  • Hardness working principle: Constant speed
  • Display: 7.0″ touch screen display
  • Constant speed range: 1 mm/sec to 3 mm/sec
  • Adjustable delays between the samples: 1 sec to 99 sec
  • Measuring princile: Constant speed
  • Printing of data and graphs: User defined templates
  • Hardness Range:3N – 800N
  • Accuracy: ±1N
  • Diameter/length measurement range: 2 – 26 mm
  • Diameter/length accuracy: ± 0 .05 mm
  • Width measurement range: 2 – 26 mm
  • Width accuracy: ± 0 .05 mm
  • Units for Hardness: N,Kp,Sc,User defined
  • Units for Thickness/diameter: mm/inch
  • Compatible weighing balance: External balance interface
  • Units for weight: g or mg
  • Size (W x D x H): 400 x 476 x 281 mm (With hood)
  • 21 CFR Part 11 Compliance: Yes with integrOS Pro
  • Electrical power: 230 VAC, 50/60 Hz, 100 W/Amp
    110 VAC, 50/60 Hz, 100 W/Amp
  • Weight: 26 kg
Electrolab

Inspire Series

Play Video
Play Video
Weight 126 kg
