Tablet Hardness Tester EHT-5P
₨ 0
The optical DO probe features comprehensive measurement capabilities for weight, thickness, diameter (length), width, and hardness. It includes a touch screen display, operates with constant speed and force, and offers advanced security, calibration alerts, programmable modes, and compliance with 21 CFR Part 11, ensuring reliable testing and documentation in pharmaceutical environments.
-
Description
-
Additional information
-
Reviews (0)
The company has a well-trained production team supported by in-house CAD, software, hardware design engineers and well established vendors to support production target and a management that understands the importance of quality and timely delivery. This together with a flexible production process and cost effective operations has enabled it to be competitive, responsive and reliable. The company provides validation and prompt after sales service for its customers needs.
Measures 5 parameters – Weight, Thickness, Diameter (Length), Width and Hardness
Full color intuitive touch screen display
Constant speed and constant force measuring principle
Up to 100 samples per test
Jaw with multi groove
3 level user management security
Indicator for calibration due date
Light and audio alarm indicator for Instrument status
Programmable calibration and verification modes
Auto / Manual mode with programmable delay time
Adjustable delay between the samples
Tablet manager tray for easy carrying of tables from weighing scale
User selectable templates for printing reports
Protective cover to protect operator from inhaling tablet dust from tablets that ‘explode’
Embedded printer for printing test results, validation and calibration reports
21 CFR part 11 compliance
10,000 product storage
Audit trial
Model: EHT-5P
Parameters: weight, Thickness, Diameter / Lenght, Width, Hardness
Compliance: Body can be stainless steel (S.S) to comply with cGMP regulations or painted MS
Display: 7.0* touch screen display
Samples per test: Up to 100
Adjustable delay between the samples: 1 sec to 99 secs
Measuring principle: constant speed
Printing of data and graphs: User defined templates
Hardness Range: 3N – 800N
Accuracy: ±1N
Jaw opening: 40mm (up to 65mm optional)
Jaw: Dual (Big and Small groove )
Units for hardness: N, Kp, Sc, user defined
Units for thickness /diameter: mm / inch
Constant speed setting: 1mm to 3 mm in step of 0.1 mm
Compatible weighing balances: Sartorius/ Mettler Toledo/Shimadzu/Contech/ Ohaus / Radwag
Security: Multi level user management ( flexible 10 role )
Hardness /thickness calibration: 2 point calibration
3 point verification linearityReport format: User defined tabular format
Interface: LAN and serial
| Weight | 126 kg |
|---|
