Instroduction:

The company has a well-trained production team supported by in-house CAD, software, hardware design engineers and well established vendors to support production target and a management that understands the importance of quality and timely delivery. This together with a flexible production process and cost effective operations has enabled it to be competitive, responsive and reliable. The company provides validation and prompt after sales service for its customers needs.

  • 7″ TFT touch screen display
  • LAN connectivity allows central printing
  • Multilevel security with password for 250 users with user programmable role
  • Alphanumeric data entry of product and user details
  • Complies with USP, IP, Ph. Eur. and JP specifications
  • Unique TimeAction™ function which allows media changeover and infinity test run, ideal for sustained and controlled release products
  • Automatic stirrer height positioning for USP 1, 2, 5, 6, intrinsic test methods
  • Easy Snap-Fit shaft locking mechanism for positive engagement and wobble free operation
  • Molded clear water bath
  • Easy to empty and clean water bath with bottom drainage
  • Precise individual vessel centering system
  • Adjustable leveling of instrument
  • Vibration free smooth motorized lift movement
  • Isolated temperature controller and water circulating pump (vibration-free & precise)
  • 1000 programmable products
  • 24 programmable sampling intervals
  • 50000 test report storage
  • Instrument accessories like paddles, baskets, vessels etc. are laser marked with serial numbers
  • Designed to minimize routine validation
  • 10 Programmable report template
  • Report for online validation of test, monograph, error log during the test
  • Programmable sample volume from 1 ml to 20 ml
  • Power failure detection and auto resume facility
  • D’light technology enabling audio visual indication of instrument status
  • Data management ( back up of Data for indivisual machine via FTP)
  • machine to machine transfer data for product method and Security via FTP
  • Biometric log in system (optional ) symbol
  • Disaster management
  • Reports can be save in the PDF Format via FTP
  • Usage history of machine ( stirrer, heater, Total number of test performed Etc )
  • Report sorting according to Review By / Approved By/Based on role access
  • View report on Screen
  • Time synchronisation based on NTP, Domain
  • Electrolab user Active/ Inactive permission set by Client
  • Audit modification events Old Data/ New Data
  • on field Software upgradation
  • static / DHCP IP Module
  • Programable Tolerences for Temperature and RP
  • Model: TrustE 8 Gen 2

  • Speed range: Variable speed from 20 to 300 RPM

  • Speed accuracy: ±0.5 RPM

  • Temperature range: 20⁰ to 40⁰ C (Extended range 10⁰ to 40⁰ C, 10⁰ to 55⁰ C and 20⁰ to 55⁰ C Optional)

  • Temperature accuracy: ± 0.1⁰ C

  • Display: 7″ intuative LCD touch screen display

  • No. of Product: 1000 maximum

  • Sample interval: Maximum 24 of 1 min to 999 hrs, 59 min

  • Printer interface: Serial port (via LAN) post script or embedded thermal printer (optional)

  • Connectivity: Ethernet, RS – 232 ,RS-485 USB

  • Bath size (L x W x H): 704 x 374 x 180 mm

  • Heater: 1 kW/230 VAC, material S.S. 304 with sensor

  • Dimensions ( W x L x H): 517x 712 x 690

  • Weight: 90Kg

  • Electric Power: 220/230 VAC, 50/60 Hz, 1.3 kW/6 Amp 110 VAC, 50/60 Hz, 1.3 kW/10 Amp

  • No. of Methods: 1000 Maximum

  • No. of Reports: 50000 Maximum

  • No. of Audit Trial: 200000 Maximum

  • Time Range: 1 min to 999 hrs, 59 min

Electrolab

Inspire Series

Play Video
Play Video
Weight 126 kg
